Electrical properties

1、Current rating: 1A ACDC

2、Voltage rating: 125V ACDC

3、Temperature range: -25℃ to 85℃

4、Contact Contact resistance:Initial value/20mΩ max

5、Insulation resistance:100MΩ min

6、Withstanding voltage:500V AC/ minute

7、Applicable wire:AWG #28 to #32

MX1.25-AB.pdf

MX1.25-AWB.pdf

MX1.25-Y.pdf

MX1.25-T.pdf
